Precision Tube & Wire Cutting Machines
SAFE, FAST AND ACCURATE
Precision measure/cut systems that are easy to set-up and use. Innovative space saving designs which loads on top and ejects from the bottom frees up the workplace. No additional material stands or racks are required for simple cutting needs. Optional accessories available to enable multi reel cutting and quick workcell set-up. The SLICE™ family of products are all programmable by lot and by batch. Each machine comes standard with safety guards and glasses.
| Technical Data | 123 | 135 | 141/142 | 230 |
|---|---|---|---|---|
| Adjustable Opening | No | No | Yes | Yes |
| Opening Width | 3″ (76.2mm) | 3″ (76.2mm) | 3″ (76.2mm) | 3″ (76.2mm) |
| Opening Height | .25″ (.64cm) fixed | .25″ (.64cm) fixed | 1.5″ (3.8cm) max/adj | 1.5″ (3.8cm) max/adj |
| Programmable | Yes-99 programs | Yes-99 programs | Yes-99 programs | Yes-150+ programs |
| Batch Programs | Yes -30/10 | Yes -30/10 | Yes -30/10 | Yes -30/10 |
| Batch Pause | Yes | Yes | Yes | Yes |
| MM and Inch Format | Yes | Yes | Yes | Yes |
| Increments | 0.10″/1mm | 0.10″/1mm | 0.10″/1mm | 0.10″/1mm |
| Max. Length | 9999 inches or mm | 9999 inches or mm | 9999 inches or mm | 9999 inches or mm |
| Max. Count | 9999 | 9999 | 9999 | 9999 |
| Adjustable Speed | Yes | Yes | Yes | Yes |
| Feed Rate | 1″(2.54cm)-30″(76.2cm)/sec | 1″(2.54cm)-30″(76.2cm)/sec | 1″(2.54cm)-30″(76.2cm)/sec | 1″(2.54cm)-30″(76.2cm)/sec |
| Max. Wire Ga. | 14 | 10 | 10 | 2 |
| Blade Type | Guillotine | Guillotine | Guillotine | Guillotine |
| Safety Guard – Opening/Exit | Exit only | Exit only | Yes | Yes |
| Air Pressure Required – psi | N/A | 80lbs | 80lbs | 80lbs |
| Voltage Required | 120/1/60 | 120/1/60 | 120/1/60 | 120/1/60 |
| E-Stop | No | No | Yes | Yes |
| Multi-Cut System Option | Yes | Yes | No | Yes |
| Tight Tolerance Kit Option | No | Yes | No | No |
| Throat Guide Option | Yes | Yes | No | No |
| Stainless Steel Wheels Option | Yes | Yes | Yes | Yes |
| Weight | 25lbs (11.4kg) | 38lbs (17.2kg) | 55lbs (25kg) | 55lbs (25kg) |
| Optical Sensor/Software | No | No | 142 ONLY | Yes |
| Warranty – *Industry Best* | 2 YR LTD | 2 YR LTD | 2 YR LTD | 2 YR LTD |
